New Replacement Cartridges for AMI Jukeboxes

AMI A-E, F40 & G40 Models

The P51 cartridge is designed to replace the now out of production Astatic #51 which was original equipment on all models A through E, plus F40 and G40

It's very close to an exact replacement for the original Astatic 51 and is available in three versions, one for 45's & two for 78's

Max recommended tracking pressure: 8 Grams for 78 play and 6 grams on 45 play

(Note: In some cases fitment my require some modifications)

Cartridge comes complete with needle and pigtail w/lugs as shown

Version #1D For use with stereo or mono 45 RPM records or new 78's only (Sold with a Diamond .7 mil stereo compliant needle) $22.99

Currently out of Stock - Expected late Oct

Version #1S For use with stereo or mono 45 RPM records or new 78's only (Sold with a Sapphire .7 mil stereo compliant needle) $19.99

Version #2 For use with original and reproduction 78 RPM records (Sold with 2 mil sapphire needle) $19.99

Version #3 For use with original 78 RPM records (Sold with 3 mil sapphire needle) $19.99

#P51 78 RPM Replacement Needles

Sapphire 2 mil tip $10

Sapphire 3 mil tip $10

P51 45 RPM Replacement Needles

Diamond .7 mil tip $12.99 (Best overall pick for 45/33 records)

Sapphire 1 mil tip $10 (Better for mono 45's, but will play stereo)

I, J & K Stereo Models

The Sonotone 8T was original equipment on I, J & K stereo models with ceramic cartridges

Brand new and a very high quality cartridge. Exact replacement item.

(Note, this version has 4 lugs Vs the original which had 3. You will need to tie the two ground logs together, otherwise it's an exact fit)

Comes as shown with mounting bracket and needle. $94.99

Stereo Compliant . 7 mil Diamond tip $13.95

AMI F Series - Continental 2

Use this AT3600 cartridge to replace GE magnetic cartridges found in all models F through Continental 2

(does not fit F40 or G40 models)

Replaces the RPX, RPJ, VRII & VR22

This is a 4 pin stereo cartridge, wire l/r channels in parallel for use on mono equipped models.

Sold as shown, 1/2" mounting  $39.99

Replacement Needles for the AT3600

Commercial Duty - Exact Replacement, Diamond Tip, $19.99

Original / Used GE RPJ-047

The GE RPJ-047 cartridge was original equipment on the AMI F80 & 120, G80, 120 & 200 plus possibly some H models and other later models with mono amps

This is a used original which has been tested

Take note: The T bar that the needle fits into and the needle is not included (needles are available onsite, but not the T bar)

Sold
